D9412GV4/D7412GV4 v2.03 | Installation and System Reference Guide | 16.0 Specifications
.
Bosch Security Systems, Inc. | 7/16 | F01U265457-09 86
16.3 Control panel Terminal Wiring
Table 33: Terminal Wiring Requirements
Terminal
No
Terminal
Description
Requirements
1 AC 18 AWG min (up to 14 AWG max)
2 AC 18 AWG min (up to 14 AWG max)
3 + AUX POWER Terminal accommodates 14 to 22 AWG, use appropriate wire size based on current
4 BATTERY - Bosch supplied wire lead, included with panel
5 BATTERY + Bosch supplied wire lead, included with panel
6 RELAY A Terminal accommodates 14 to 22 AWG, use appropriate wire size based on current
7 RELAY B Terminal accommodates 14 to 22 AWG, use appropriate wire size based on current
8 RELAY C Terminal accommodates 14 to 22 AWG, use appropriate wire size based on current
9 COMMON Terminal accommodates 14 to 22 AWG, use appropriate wire size based on current
10 EARTH
GROUND
14 to 16 AWG
11 POINT 1 Terminal accommodates 14 to 22 AWG, use appropriate wire size based on loop
resistance less than 100 Ω
12 POINT 1/2
COMMON
Terminal accommodates 14 to 22 AWG, use appropriate wire size based on loop
resistance less than 100
Ω
13 POINT 2 Terminal accommodates 14 to 22 AWG, use appropriate wire size based on loop
resistance less than 100 Ω
14 POINT 3 Terminal accommodates 14 to 22 AWG, use appropriate wire size based on loop
resistance less than 100 Ω
15 POINT 3/4
COMMON
Terminal accommodates 14 to 22 AWG, use appropriate wire size based on loop
resistance less than 100
Ω
16 POINT 4 Terminal accommodates 14 to 22 AWG, use appropriate wire size based on loop
resistance less than 100
Ω
17 POINT 5 Terminal accommodates 14 to 22 AWG, use appropriate wire size based on loop
resistance less than 100
Ω
18 POINT 5/6
COMMON
Terminal accommodates 14 to 22 AWG, use appropriate wire size based on loop
resistance less than 100
Ω
19 POINT 6 Terminal accommodates 14 to 22 AWG, use appropriate wire size based on loop
resistance less than 100 Ω
