D9412GV4/D7412GV4 v2.03 | Installation and System Reference Guide | 9.0 Off-Board Points
.
Bosch Security Systems, Inc. | 7/16 | F01U265457-09 53
assigned to Points 17 through 24. Moving the DIP
switch for Point 4 to the OFF position would
effectively disable Point 20, allowing normal
operation of the D9210C and the OctoPOPIT.
Through panel configuration the Point Source
prompt further protects from possible point
addressing conflicts. A point can be ZONEX,
Octo-input, SDI2 Wireless, or Door Point.
Terminate each OctoPOPIT sensor loop with a 1 k
Ω EOL resistor. Attach a resistor even if you do
not enable the loop.
9.4.5 Mounting OctoPOPITs
The D8128D OctoPOPIT Module can be installed
in the enclosure with the control panel using
standard four-conductor 22 AWG (0.8 mm) wire,
or in a separate enclosure (Model D8103,
D8103A, or D8109) up to 200 ft (61 m) from the
control panel using shielded (recommended)
standard four-conductor 22 AWG (0.8 mm) wire.
If using the D125B or D129, refer to the
Specifications section of the D8128D Installation
Guide (P/N: F01U070537) for cabling
requirements.
For UL Listed systems, mount the D8128D in a
tamper-proof enclosure. To install OctoPOPITs in
the control panel’s enclosure, complete the
following procedure. Use the D137 Mounting
Bracket to install OctoPOPITs in enclosures with
no module-mounting locations available.
1. Align the OctoPOPIT module using any of the
four mounting locations in the enclosure.
Refer to Figure 2 on page 20.
2. Use the screws provided with the module to
secure it in the enclosure.
9.4.6 Wiring OctoPOPITs
Warning: Disconnect all power to the
control panel before beginning any
work with the internal components.
Serious injury could result from
electrical shock.
1. Power down the control panel:
a. Disconnect the positive (red) battery
lead at the battery.
b. Unplug the transformer.
A D8128D OctoPOPIT can be installed
up to 200 ft (61 m) from the control
panel.
2. Connect the D8128D to the control panel
using either of the following methods:
a. Wire the D8128D to the terminal strip on
the side of the POPEX Module, or
b. Connect the D8128D using the
interconnect wiring connectors (P1 and
P2). Refer to Using Interconnect Wiring
on page 56.
Caution - AC induction: Avoid
installing Zonex data wires and Zonex
input (sensor loop) wires around any
AC conduit, wiring, or electrical
devices that emit fields of
electromagnetic interference (EMI).
Using the Terminal Strip
Refer to Table 16, Figure 18 on page 54, and
Figure 19 on page 55 when using the terminal
strip to connect the D8128D OctoPOPIT to the
control panel.
Table 16: Terminal Strip Connections
D8128D D9412GV4 D7412GV4
Common Terminal 23 Terminal 23
Out Zonex 1 = Terminal 27
Zonex 2 = Terminal 25
Terminal 27
In Zonex 1 = Terminal 28
Zonex 2 = Terminal 26
Terminal 28
+12 V Terminal 24 Terminal 24
