D9412GV4/D7412GV4 v2.03 | Installation and System Reference Guide | 17.0 Approved Applications
.
Bosch Security Systems, Inc. | 7/16 | F01U265457-09 89
UL Listed Model 5110 Bell
UL Listed Model 4001-42 External Line
Balancer
Bell Test at Arming: UL Standard 365
requires a Bell Test at arming for bank
safe and vault applications.
17.3.4 System Configuration Requirements
The following configuration and programming
options are required for UL Bank Safe and
Vault Systems. Refer to the Control Panels
(D9412GV4/D7412GV4 v2.03) Program Entry
Guide (P/N: F01U265459) for programming
information.
Safe and Vault Protective Circuits
To test the devices that protect the safe(s) or
vault(s) without sounding the bell, specify the
devices’ points as controlled zones and
supervised for trouble conditions. Refer to
Point Index in the Control Panels
(D9412GV4/D7412GV4 v2.03) Program Entry
Guide (P/N: F01U265459) for more
information.
Bell Configuration
UL 365 requires the bell time to be 15 to 30
min. The Rothenbuhler 5110 Bell provides
selectable bell time through manipulation of its
jumpers. Refer to the manufacturer’s
installation instructions for more information.
In addition to the jumper settings inside the
bell, you can activate the control panel for a
bell time of 15 min.
UL 365 requires a Bell Test at arming and must
be enabled in control panel programming.
Refer to Bell Parameters in the Control Panels
(D9412GV4/D7412GV4 v2.03) Program Entry
Guide (P/N: F01U265459) for more bell time
and test programming information.
Bell Test
To enable the bell test feature, you enable an
unused area of the control panel. Enable the
bell test feature for the unused area only.
Program Relay B as the area bell relay for the
unused area.
All pass codes with authority to arm the safe or
vault and also send a Closing Report must be
valid in this area. Program the area for a five-
second exit delay. Refer to Figure 13 on page
44 for test connections. To complete the
installation for this feature, connect the output
to a D133 Relay Module.
17.3.5 Exit Delay
The control panel’s programmed maximum exit
delay must not exceed 30 sec.
17.3.6 Equipment Requirements
D9412GV4/D7412GV4 V2.03 Control Panel
Two (2) D126 12 V, 7 Ah batteries
Two (2) D1218 12 V 18 Ah batteries
B520 Auxiliary Power Supply Module/or
D8132 Battery Charger Module
Two (2) D8108A Enclosures
D122 Dual Battery Harness
D122L Dual Battery Harness
D133 Relay Module
EVD System (Listed Safe/Vault)
17.4 Fire Applications
UL Listed fire initiating devices not requiring
electrical compatibility evaluation can be used
in any application. For example, the four-wire
smoke detectors, heat detectors, waterflow
switches, and manual pull stations are suitable
fire initiating devices. Consult the individual
component specification and installation
documents to determine suitability.
UL requires any device powered
from a power output to be
supervised.
UL requires that power outputs are
not shared between fire and non-
fire devices unless all devices are in
conduit within 20 ft and are in the
same room.
The expansion bus can be shared
between fire and non-fire devices
where the POPIT module is
providing data isolation between
the input and the bus connections.
