D9412GV4/D7412GV4 v2.03 | Installation and System Reference Guide | 4.0 Installation
.
Bosch Security Systems, Inc. | 7/16 | F01U265457-09 24
After system installation and any
control panel programming, perform a
complete system test (UL 864
requirement). A complete system test
includes testing the control panel, all
devices, and communication paths for
proper operation.
Refer to Section 4.11 Service Walk Test on page
24 for complete Service Walk Test instructions.
Clear after Test: To clear the event memory and
report buffer, momentarily close the reset pin.
Events stored in the control panel’s event log are
not cleared.
4.11 Service Walk Test
The Service Walk Test differs from the standard
Walk Test. In the standard Walk Test, points that
are not programmed in the control panel do not
appear in the test. In the Service Walk Test, on-
board and expanded points that are not
programmed in the control panel do appear in
the test.
The Service Walk Test allows a user to walk test
all 246 points from a control-panel-wide keypad,
regardless of the point index type.
A Service Walk Test can also be initiated by
account-wide or area-wide keypads but test only
those points that are within the scope of the
keypad that initiated the function. The Service
Walk Test does not test points in armed areas.
Only Walk Test Start and Walk Test
End are reported to the central
station.
During a Service Walk Test, the
summary alarm outputs remain off,
because there are no alarm conditions
to summarize.
Service Walk Test Procedure (B915/B920/
B921C /B930/B942/B942W)
Refer to Walk Test procedures for Service Walk
Test options in compatible keypad
documentation when using a B915, B920, B921C,
B930, or B942/B942W Keypad.
1. Choose a keypad to conduct the test. Ensure
that the display shows the idle disarmed text.
2. Open the Main menu and then go to the [3]
Actions > [3] Test > [1] Walk Test > [3]
Service menu option.
3. Enter your passcode or present token (B942)
and press [ENTER]. The keypad shows the
number of points that remain to be tested.
4. To view the points, press [ENTER] on a
B915/B920/ B921C keypad or press View
untested points on a B930/B942/B942W
keypad. To scroll through the list of points,
use the [PREV]/ or [NEXT]/ key.
5. When you fault a point (move in front of a
motion sensor for example), the keypad emits
a brief tone and shows the point name and
information (for example, Area-1 Point-7
Onboard: Short).
Extra Points display default text: If the
switches on a POPIT are set incorrectly to a
point number that is not in the program for the
control panel, the default text for that point
number (PT ###) appears when the point is
faulted.
Faulting the point a second time produces the
tone and shows the point text, but does not
decrease the count in the ## PTS TO TEST
message.
To see the points that remain untested during the
Service Walk Test:
a. Press [ESC]/ when point text appears.
The display shows ## PTS TO TEST.
b. Press the [ESC]/ key. VIEW UNTESTED
? appears.
c. Press [ENT]. ## PTS UNTESTED appears.
d. Press [NEXT]/ to see a list of the points
that have not yet been tested. Move
through this list by pressing the
[NEXT]/ key.
e. To resume the Service Walk Test, press
[ESC]/ . ## PTS UNTESTED appears.
f. Press [ESC]/ . ## PTS TO TEST appears.
g. Resume testing points. To end the Service
Walk Test, press [ESC]/ twice.
h. After the last point is tested, 0 PTS TO
TEST appears. Press [ESC]/ . The
display shows ALL PTS TESTED briefly
before returning to idle text.
