Dell PowerVault MD3200i User Manual

Configuration: Disk Groups and Virtual Disks 147
8 Click OK .
Suspending the Media Scan
You cannot perform a media scan while performing another long-running
operation on the disk drive such as reconstruction, copy-back,
reconfiguration, virtual disk initialization, or immediate availability
formatting. If you want to perform another long-running operation, you must
suspend the media scan.
NOTE: A background media scan is the lowest priority of the long-running
operations.
To suspend a media scan:
1
In the AMW, select the Logical tab and select any virtual disk.
2 Select Virtual Disk  Change  Media Scan Settings .
The
Change Media Scan Settings window is displayed.
3 Select Suspend media scan .
NOTE: This applies to all the virtual disks on the disk group.
4 Click OK .
book.book Page 147 Saturday, September 24, 2011 9:06 AM

Dell PowerVault MD3200i Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Maximum supported storage capacity	115.2 TB
Number of storage drives installed	12
Interface	RJ-45, SAS, PS/2
Connector(s)	4x RJ-45, 1x 6Gb SAS, 1x PS/2
Power supply type	AC
Dimensions (WxDxH)	446.3 x 561 x 86.8 mm
Power requirements	90 - 264 V, 47 - 63 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows, Linux, VMware, Hyper-V
Internal	No
LED indicators	HDD, Power, Power fail, Status
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (typical)	25 W
Power supply unit (PSU) capacity	600 W

Weight and Dimensions

Weight	29300 g
