20 Introduction
• Mounting rails (2) (optional)
• MD3200i
Series resource media
•
Rack Installation Instructions .
•
Getting Started With Your System (provides an overview of enclosure
features, setting up your enclosure, and technical specifications).
MD3200i Series Storage Array
The Dell PowerVault MD3200i Series is a 2U rack-mounted external
redundant array of independent disks (RAID) storage array capable of
accommodating up to twelve 3.5" or twenty four 2.5" 6.0-Gbps Serial-
Attached SCSI (SAS) disks. The MD3200i Series storage arrays can be daisy-
chained with MD1200 Series expansion enclosures, providing access to a
maximum of 120 disks (or 192 disks with Premium Feature activation) in the
entire storage system. Connectivity between the storage array and the host
server is provided by a standard Ethernet connection.
Dell PowerVault Modular Disk Storage Manager
Dell PowerVault Modular Disk Storage Manager (MDSM) is a graphical user
interface (GUI) application, used to configure and manage one or more
MD3200i Series Storage Arrays. The MDSM software is located on the
MD3200i Series resource media.
Dell PowerVault Modular Disk Configuration Utility
Dell PowerVault Modular Disk Configuration Utility (MDCU) is an iSCSI
configuration wizard that can be used in conjunction with MDSM to simplify
the configuration of iSCSI connections. The MDCU software is located on
the MD3200i Series resource media.
Other Information You May Need
WARNING: See the safety and regulatory information that shipped with your
system. Warranty information may be included within this document or as a
separate document.
•The Getting Started Guide provides an overview of setting up and cabling
your storage array.
book.book Page 20 Saturday, September 24, 2011 9:06 AM

Dell PowerVault MD3200i Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Maximum supported storage capacity	115.2 TB
Number of storage drives installed	12
Interface	RJ-45, SAS, PS/2
Connector(s)	4x RJ-45, 1x 6Gb SAS, 1x PS/2
Power supply type	AC
Dimensions (WxDxH)	446.3 x 561 x 86.8 mm
Power requirements	90 - 264 V, 47 - 63 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows, Linux, VMware, Hyper-V
Internal	No
LED indicators	HDD, Power, Power fail, Status
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (typical)	25 W
Power supply unit (PSU) capacity	600 W

Weight and Dimensions

Weight	29300 g
