Management: Firmware Downloads 207
disk called DACstore. DACstore and the physical disk firmware enable easier
reconfiguration and migration of the physical disks. The physical disk
firmware performs these functions:
• The physical disk firmware records the location of the physical disk in an
expansion enclosure. If you take a physical disk out of an expansion
enclosure, you must insert it back into the same physical disk slot, or the
physical disk firmware cannot communicate with the RAID controller
module or other storage array components.
• RAID configuration information is stored in the physical disk firmware and
is used to communicate with other RAID components.
CAUTION: Risk of application errors – Downloading the firmware could cause
application errors.
Keep these important guidelines in mind when you download firmware to
avoid the risk of application errors:
• Downloading firmware incorrectly could result in damage to the physical
disks or loss of data. Perform downloads only under the guidance of your
Technical Support representative.
• Stop all I/O to the storage array before the download.
• Make sure that the firmware that you download to the physical disks are
compatible with the physical disks that you select.
• Do not make any configuration changes to the storage array while
downloading the firmware.
NOTE: Downloads can take several minutes to complete. During a download, the
Download Physical Disk - Progress dialog is displayed. Do not attempt another
operation when the Download Physical Disk - Progress dialog is shown.
To download Physical Disk Firmware:
1
From the AMW, select
Advanced
Maintenance
Download
Physical Disk.
The
Download Physical Disk - Introduction
window is displayed.
2
Click
Next
.
The
Download Physical Disk Firmware - Add Packages
window is
displayed.
3
In the
Selected Packages
area, click
Add
.
book.book Page 207 Saturday, September 24, 2011 9:06 AM
