Dell PowerVault MD3200i User Manual

Configuration: Using iSCSI 85
Initiator CHAP Secret
The initiator CHAP secret is set on the host using the iSCSI initiator
configuration program provided with the host operating system. If you are
using the mutual authentication method, you must define the initiator
CHAP secret when you set up the host. This must be the same CHAP secret
that is defined for the target when defining mutual authentication settings.
Target CHAP Secret
If you are using CHAP secrets, you must define the CHAP secret for the
target.
Valid Characters for CHAP Secrets
The CHAP secret must be between 12 and 57 characters. The CHAP secret
supports characters with ASCII values of 32 to 126 decimal. See Table 7-1 for
a list of valid ASCII characters.
Table 7-1. Valid ASCII Characters for CHAP Secrets
Valid ASCII Characters for CHAP Secrets
Space ! " # $ % & ’ ( ) * +
, -./01 23 45 67
8 9:;<=>? @ABC
DEFGHIJKLMNO
PQRSTUVWXYZ[
\]^_abcdefgh
ijklmnopqrst
u vwxyz {| }~
book.book Page 85 Saturday, September 24, 2011 9:06 AM

Dell PowerVault MD3200i Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Maximum supported storage capacity	115.2 TB
Number of storage drives installed	12
Interface	RJ-45, SAS, PS/2
Connector(s)	4x RJ-45, 1x 6Gb SAS, 1x PS/2
Power supply type	AC
Dimensions (WxDxH)	446.3 x 561 x 86.8 mm
Power requirements	90 - 264 V, 47 - 63 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows, Linux, VMware, Hyper-V
Internal	No
LED indicators	HDD, Power, Power fail, Status
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (typical)	25 W
Power supply unit (PSU) capacity	600 W

Weight and Dimensions

Weight	29300 g
