Dell PowerVault MD3200i User Manual

Configuration: Premium Feature—Snapshot Virtual Disks 171
Canceling a Snapshot Rollback
WARNING: Risk of data loss: If you cancel a snapshot rollback in progress, the
base virtual disk may remain in an unusable state and the snapshot virtual disk is
displayed as failed in the MD storage management software. Therefore, do not
cancel a snapshot rollback unless reliable recovery options exist for restoring the
content of the base virtual disk.
1 In the array management window, select the Logical tab.
2 Choose one:
• Select the snapshot virtual disk, and select
Virtual Disk  Snapshot 
Cancel Rollback .
• Right-click the snapshot virtual disk and select
Cancel Rollback .
The
Confirm Cancel Rollback dialog is displayed.
3 To cancel the snapshot rollback, type yes in the confirmation box and
click
OK .
4 Click Yes to cancel the rollback operation.
book.book Page 171 Saturday, September 24, 2011 9:06 AM

Dell PowerVault MD3200i Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Maximum supported storage capacity	115.2 TB
Number of storage drives installed	12
Interface	RJ-45, SAS, PS/2
Connector(s)	4x RJ-45, 1x 6Gb SAS, 1x PS/2
Power supply type	AC
Dimensions (WxDxH)	446.3 x 561 x 86.8 mm
Power requirements	90 - 264 V, 47 - 63 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows, Linux, VMware, Hyper-V
Internal	No
LED indicators	HDD, Power, Power fail, Status
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (typical)	25 W
Power supply unit (PSU) capacity	600 W

Weight and Dimensions

Weight	29300 g
