Dell PowerVault MD3200i User Manual

Configuration: Premium Feature—Snapshot Virtual Disks 157
– Dell recommends placing the snapshot repository virtual disk within
the disk group of the source virtual disk. This ensures that if drives
associated with the disk group are moved to another storage array, all
the virtual disks associated with the snapshot virtual disk remain in
the same group.
• Snapshot Repository Virtual Disk Capacity—The snapshot repository
virtual disk capacity is expressed as a percentage of the source virtual disk
capacity (maximum 220 percent).
• Percent Full—When the snapshot repository virtual disk reaches the user-
specified repository full percentage level, the event is logged in the Major
Event Log (MEL). The default snapshot repository full percentage level is
50% of the source virtual disk.
• Snapshot Repository Virtual Disk Full Conditions—Choose whether to
fail writes to the source virtual disk or fail the snapshot virtual disk when
the snapshot repository virtual disk becomes full.
• Host-to-Virtual Disk Mapping—Choose whether to map the snapshot
virtual disk to a host or host group now or to map the snapshot virtual disk
later. The default setting is Map later.
• Schedule—Creates the snapshot virtual disk at a specified time, or
according to a regularly occurring interval. If no schedule is specified, the
snapshot operation begins immediately. This parameter can also be used to
apply a schedule to an existing snapshot virtual disk.
Preparing Host Servers to Create the Snapshot Using the Advanced Path
NOTE: Before using the Snapshot Virtual Disks Premium Feature in a Microsoft
Windows clustered configuration, you must first map the snapshot virtual disk to
the cluster node that owns the source virtual disk. This ensures that the cluster
nodes correctly recognize the snapshot virtual disk.
NOTE: Mapping the snapshot virtual disk to the node that does not own the source
virtual disk before the Snapshot enabling process is completed can result in the
operating system mis-identifying the snapshot virtual disk. This, in turn, can result in
data loss on the source virtual disk or an inaccessible snapshot.
NOTE: For more information on mapping the snapshot virtual disk to the secondary
node, see the Dell PowerVault MD3200i and MD3220i Storage Arrays With
Microsoft Windows Server Failover Clusters at support.dell.com/manuals.
book.book Page 157 Saturday, September 24, 2011 9:06 AM

Dell PowerVault MD3200i Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Maximum supported storage capacity	115.2 TB
Number of storage drives installed	12
Interface	RJ-45, SAS, PS/2
Connector(s)	4x RJ-45, 1x 6Gb SAS, 1x PS/2
Power supply type	AC
Dimensions (WxDxH)	446.3 x 561 x 86.8 mm
Power requirements	90 - 264 V, 47 - 63 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows, Linux, VMware, Hyper-V
Internal	No
LED indicators	HDD, Power, Power fail, Status
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (typical)	25 W
Power supply unit (PSU) capacity	600 W

Weight and Dimensions

Weight	29300 g
