222 Management: Installing Array Components
Installing a RAID Controller Module
CAUTION: Many repairs may only be done by a certified service technician. You
must only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1
Insert the RAID controller module into the RAID controller module bay
until it seats into place.
2
Push the release lever toward the chassis until it clicks into place.
3
Connect all the cables to the RAID controller module.
4
If applicable, update the firmware for the RAID controller module. For
information about the latest firmware, see
support.dell.com
.
Opening the RAID Controller Module
CAUTION: Many repairs may only be done by a certified service technician. You
must only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1
Turn off the array and host server.
2
Disconnect all the power cables connected to the array.
3
Remove the RAID controller module. See "Removing a RAID Controller
Module Blank" on page 219.
4
Remove the screws from the sides of the RAID controller module. See
Figure 16-9.
5
While pressing the indent, slide the cover in the direction of the arrow and
lift it away from the RAID controller module. See Figure 16-9.
