Dell PowerVault MD3200i User Manual

92 Configuration: Using iSCSI
Edit, Remove, or Rename Host Topology
If you give access to the wrong host or the wrong host group, you can remove
or edit the host topology. To correct the host topology:
For more information about Host, Host Groups, and Host Topology, see
"Configuration: About Your Host" on page 95.
Table 7-3. Host Topology Actions
Desired Action Steps
Move a host.
Move a host group.
1 Click the Mappings tab.
2 Select the Host that you want to move, and then click
Mappings  Move .
3 Select a host group to move the host to and click OK .
Manually delete the
host, the host group.
1 Click the Mappings tab.
2 Select the item that you want to remove and select
Mappings  Remove .
Rename the host, the
host group.
1 Click the Mappings tab.
2 Select the item that you want to rename and select
Mappings  Rename .
3 Type a new label for the host and click OK .
book.book Page 92 Saturday, September 24, 2011 9:06 AM

Dell PowerVault MD3200i Specifications

General

HDD speed	15000 RPM
RAID levels	0, 1, 5, 6, 10
Storage drive capacity	600 GB
Storage drive interface	Serial Attached SCSI (SAS)
Maximum supported storage capacity	115.2 TB
Number of storage drives installed	12
Interface	RJ-45, SAS, PS/2
Connector(s)	4x RJ-45, 1x 6Gb SAS, 1x PS/2
Power supply type	AC
Dimensions (WxDxH)	446.3 x 561 x 86.8 mm
Power requirements	90 - 264 V, 47 - 63 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows, Linux, VMware, Hyper-V
Internal	No
LED indicators	HDD, Power, Power fail, Status
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Power consumption (typical)	25 W
Power supply unit (PSU) capacity	600 W

Weight and Dimensions

Weight	29300 g
