Command
line
interface
Command
line
reference
IX30
User
Guide
1005
grep
Grep
the
contents
of
a
file.
Syntax
grep
<match>
<path>
Parameters
match:
Output
all
lines
in
file
matching
string.
path:
The
file
to
grep.
help
Show
CLI
editing
and
navigation
commands.
Syntax
help
Parameters
None
1004
1006
