Routing IP routing
IX30 User Guide
282
Configure a routing policy
Required configuration items
n
The packet matching parameters. It can any combination of the following:
l
Source interface.
l
Source address. This can be a firewall zone, an interface, a single IPv4/IPv6 address or
network, or a MACaddress.
l
Destination address. This can be a firewall zone, an interface, a single IPv4/IPv6 address or
network, or a domain.
l
Protocol. This can be any, tcp, udp or icmp.
l
Source port. This is only used if the protocol is set to tcp or udp.
l
Destination port. This is only used if protocol is set to tcp or udp.
n
The network interface used to reach the destination.
Additional configuration items
n
A label for the routing policy.
n
Whether packets that match this policy should be dropped when the gateway interface is
disconnected, rather than forwarded through other interfaces.
To configure a routing policy:
Web
1. Log into Digi Remote Manager, or log into the local Web UI as a user with full Admin access
rights.
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
