Routing Virtual Router Redundancy Protocol (VRRP)
IX30 User Guide
328
2. Set the IP address for ETH2:
(config)> network interface eth2 ipv4 address 192.168.3.1/24
(config)>
Task 4: Configure the DHCP server for ETH2 on device one
1. Set the start and end addresses of the DHCP pool to use to assign DHCP addresses to clients:
a. Set the start address to 100:
(config)> network interface eth2 ipv4 dhcp_server lease_start 100
(config)>
b. Set the end address to 199:
(config)> network interface eth2 ipv4 dhcp_server lease_end 199
(config)>
2. Set the DHCP server gateway type to custom:
(config)> network interface eth2 ipv4 dhcp_server advanced gateway custom
(config)>
3. Set the custom gateway to 192.168.3.3:
(config)> network interface eth2 ipv4 dhcp_server advanced gateway_custom
192.168.3.3
(config)>
4. Save the configuration and apply the change:
(config)> save
Configuration saved.
>
5. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Configure device two (backup device)
Web
Task 1: Configure VRRP on device two
1. Log into Digi Remote Manager, or log into the local Web UI as a user with full Admin access
rights.
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
