Digital Input/Output and Analog Input Send digital and analog I/O monitoring information to a remote server
IX30 User Guide
834
6. To clear the calibration, click Calibration Reset.
7. Repeat for additional analog input pins.
Command line
1. Select the device in Remote Manager and click Actions > Open Console, or log into the IX30
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. To calibrate the low and high ends of the analog input range for analog input ports:
a. To calibrate the low end of the analog input range for analog input port 1 (ain1):
> ain calibrate ain1 low int
>
where int is an integer representing the voltage in mV, or the current, in uA, that is
connected to the analog input.
b. To calibrate the high end of the analog input range for analog input port 1 (ain1):
> ain calibrate ain1 high int
>
where int is an integer representing the voltage in mV, or the current in uA, that is
connected to the analog input.
c. Repeat as necessary for analog inputs ain2, ain3, and ain4.
3. To rest the calibration:
a. To reset the calibration for ain1:
> ain calibration-reset ain1
b. Repeat as necessary for analog inputs ain2, ain3, and ain4.
4. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Send digital and analog I/O monitoring information to a remote
server
Required configuration items
n
One or more remote servers to send digital and/or analog I/O monitoring information to.
n
The port on the remote server that will listen for monitoring information.
Additional configuration items
n
The communication protocol (either TCP or UDP).
n
The polling period that the device will use to gather monitoring information.
