7.5 Advanced menus
The advanced menus consist of groups or parameters appropriate to a
specific function or feature of the drive. Menus 0 to 22 can be viewed on
all keypads. Menus 40 and 41 are specific to the SM-Keypad Plus
(LCD). Menus 70 to 91 can be viewed with an SM-Keypad Plus (LCD)
only when an SM-Applications is installed.
Table 7-1 Advanced menu descriptions
7.5.1 SM-Keypad set-up menus
Table 7-2 Menu 40 parameter descriptions
Table 7-3 Menu 41 parameter descriptions
Menu Description LED LCD
0
Commonly used basic set up parameters for quick
/ easy programming
99
1 Frequency / speed reference 99
2Ramps 99
3
Slave frequency, speed feedback and speed
control
99
4 Torque and current control 99
5 Motor control 99
6 Sequencer and clock 99
7 Analog I/O 99
8 Digital I/O 99
9
Programmable logic, motorized pot and binary
sum
99
10 Status and trips 99
11 General drive set-up 99
12 Threshold detectors and variable selectors 99
13 Position control 99
14 User PID controller 99
15,
16, 17
Solutions Module set-up 99
18 Application menu 1 99
19 Application menu 2 99
20 Application menu 3 99
21 Second motor parameters 99
22 Additional Menu 0 set-up 99
40 Keypad configuration menu X 9
41 User filter menu X 9
70 PLC registers X 9
71 PLC registers X 9
72 PLC registers X 9
73 PLC registers X 9
74 PLC registers X 9
75 PLC registers X 9
85 Timer function parameters X 9
86 Digital I/O parameters X 9
88 Status parameters X 9
90 General parameters X 9
91 Fast access parameters X 9
Parameter
Range(
Ú)
40.00 Parameter 0 0 to 32767
40.01 Language selection
English (0), Custom (1),
French (2), German (3),
Spanish (4), Italian (5)
40.02 Software version
999999
40.03 Save to flash
Idle (0), Save (1),
Restore (2), Default (3)
40.04 LCD contrast
0 to 31
40.05
Drive and attribute database
upload was bypassed
Updated (0), Bypass (1)
40.06 Browsing favourites control
Normal (0), Filter (1)
40.07 Keypad security code
0 to 999
40.08
Communication channel
selection
Disable (0), Slot1 (1), Slot2
(2), Slot3 (3), Slave (4),
Direct (5)
40.09 Hardware key code
0 to 999
40.10 Drive node ID (Address)
0 to 255
40.11 Flash ROM memory size
4Mbit (0), 8Mbit (1)
40.18
Assistance on action threshold
parameter
0 to 499.99
40.19 String database version number 0 to 999999
40.20 Screen saver strings and enable
None (0), Default (1),
User (2)
40.21 Screen saver interval
0 to 600
40.22 Turbo browse time interval
0 to 200ms
Parameter
Range(
Ú)
41.00 Parameter 0 0 to 32767
41.01
to
41.50
Browsing filter source F01 to F50 Pr 0.00 to Pr 391.51
41.51 Browsing favourites control Normal (0), Filter (1)
