198 Unidrive SPM User Guide
www.controltechniques.com Issue Number: 3
13.10 Menu 10: Status and trips
*The value given for the range is that obtained via serial communication.
For the text string displayed on the drive, see Chapter 15 Diagnostics on
page 275.
Parameter
Range(
Ú) Default(Ö)
Type
OL CL OL VT SV
10.01 Drive OK OFF (0) or On (1)
RO Bit NC PT
10.02 Drive active OFF (0) or On (1)
RO Bit NC PT
10.03 Zero speed OFF (0) or On (1)
RO Bit NC PT
10.04
Running at or below minimum
speed
OFF (0) or On (1)
RO Bit NC PT
10.05 Below set speed OFF (0) or On (1)
RO Bit NC PT
10.06 At speed OFF (0) or On (1)
RO Bit NC PT
10.07 Above set speed OFF (0) or On (1)
RO Bit NC PT
10.08 Load reached OFF (0) or On (1)
RO Bit NC PT
10.09 Drive output is at current limit OFF (0) or On (1)
RO Bit NC PT
10.10 Regenerating OFF (0) or On (1)
RO Bit NC PT
10.11 Braking IGBT active OFF (0) or On (1)
RO Bit NC PT
10.12 Braking resistor alarm OFF (0) or On (1)
RO Bit NC PT
10.13 Direction commanded OFF (0) or On (1) [0 = FWD, 1 = REV]
RO Bit NC PT
10.14 Direction running OFF (0) or On (1) [0 = FWD, 1 = REV]
RO Bit NC PT
10.15 Line powersupply loss OFF (0) or On (1)
RO Bit NC PT
10.16 Under voltage active OFF (0) or On (1)
RO Bit NC PT
10.17 Overload alarm OFF (0) or On (1)
RO Bit NC PT
10.18 Drive over temperature alarm OFF (0) or On (1)
RO Bit NC PT
10.19 Drive warning OFF (0) or On (1)
RO Bit NC PT
10.20 Trip 0 0 to 230*
RO Txt NC PT PS
10.21 Trip 1 0 to 230*
RO Txt NC PT PS
10.22 Trip 2 0 to 230*
RO Txt NC PT PS
10.23 Trip 3 0 to 230*
RO Txt NC PT PS
10.24 Trip 4 0 to 230*
RO Txt NC PT PS
10.25 Trip 5 0 to 230*
RO Txt NC PT PS
10.26 Trip 6 0 to 230*
RO Txt NC PT PS
10.27 Trip 7 0 to 230*
RO Txt NC PT PS
10.28 Trip 8 0 to 230*
RO Txt NC PT PS
10.29 Trip 9 0 to 230*
RO Txt NC PT PS
10.30 Full power braking time 0.00 to 400.00 s 0.00 RW Uni US
10.31 Full power braking period 0.0 to 1500.0 s 0.0 RW Uni US
10.32 External trip OFF (0) or On (1) OFF (0) RW Bit NC
10.33 Drive reset OFF (0) or On (1) OFF (0) RW Bit NC
10.34 No. of auto-reset attempts 0 to 5 0 RW Uni US
10.35 Auto-reset delay 0.0 to 25.0 s 1.0 RW Uni US
10.36
Hold drive OK until last
attempt
OFF (0) or On (1) OFF (0) RW Bit US
10.37 Action on trip detection 0 to 15 0 RW Uni US
10.38 User trip 0 to 255 0 RW Uni NC
10.39
Braking energy overload
accumulator
0.0 to 100.0 %
RO Uni NC PT
10.40 Status word 0 to 32,767
RO Uni NC PT
10.41 Trip 0 time: years.days 0.000 to 9.365 years.days
RO Uni NC PT PS
10.42
Module number for trip 0, or, Trip 0
time: hours.minutes
00.00 to 23.59 hours.minutes
RO Uni NC PT PS
10.43
Module number for trip 1, or, Trip 1 time
0 to 600.00 hours.minutes RO Uni NC PT PS
10.44
Module number for trip 2, or, Trip 2 time
0 to 600.00 hours.minutes RO Uni NC PT PS
10.45
Module number for trip 3, or, Trip 3 time
0 to 600.00 hours.minutes RO Uni NC PT PS
10.46
Module number for trip 4, or, Trip 4 time
0 to 600.00 hours.minutes RO Uni NC PT PS
10.47
Module number for trip 5, or, Trip 5 time
0 to 600.00 hours.minutes RO Uni NC PT PS
10.48
Module number for trip 6, or, Trip 6 time
0 to 600.00 hours.minutes RO Uni NC PT PS
10.49
Module number for trip 7, or, Trip 7 time
0 to 600.00 hours.minutes RO Uni NC PT PS
10.50
Module number for trip 8, or, Trip 8 time
0 to 600.00 hours.minutes RO Uni NC PT PS
10.51
Module number for trip 9, or, Trip 9 time
0 to 600.00 hours.minutes RO Uni NC PT PS
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
