Unidrive SPM User Guide 27
Issue Number: 3 www.controltechniques.com
Figure 4-3 Layout for an Unidrive SPMD module operating on a 3-phase supply
*Refer to Table 6-16, Table 6-17 on page 74 and Table 6-18 on page 75 for technical data and part numbers.
**Fuses are needed only if the power supply has a current rating of more than 10A.
***Refer to Table 6-2, Table 6-3, Table 6-4 and Table 6-5 on page 68 for technical data and part numbers.
****Refer to section 14.1.3 Supply requirements on page 267 for supply requirements.
Line reactor***
Rectifier to
inverter
To Next Page
