Unidrive SPM User Guide 267
Issue Number: 3 www.controltechniques.com
Table 14-12 Input line reactor losses @ 40/50°C (104/122°F) ambient
Table 14-13 Output sharing choke losses @ 40/50°C (104/122°F) ambient
14.1.3 Supply requirements
Voltage:
SPMXX20X 200V to 240V ±10%
SPMXX40X 380V to 480V ±10%
SPMXX60X 500V to 690V ±10%
Number of phases: 3
Maximum supply imbalance: 2% negative phase sequence (equivalent
to 3% voltage imbalance between phases).
Frequency range: 48 to 65 Hz
For UL compliance only, the maximum supply symmetrical fault current
must be limited to 100kA
Unidrive SPMA/D heatsink fan supply requirements
Nominal voltage: 24V
Minimum voltage: 23.5V
Maximum voltage: 27V
Current drawn:
SPMA (all) 3.3A
SPMD12X1 to 12X4 3.3A
SPMD14X1 and 14X2 3.3A
SPMD14X3 and 14X4 4.5A
SPMD16X1 and 16X2 3.3A
SPMD16X3 and 16X4 4.5A
Recommended power supply: 24V, 5A
Recommended fuse:
SPMA (all) 4A fast blow (I
2
t <20A
2
s)
SPMD12X1 to 12X4 4A fast blow (I
2
t <20A
2
s)
SPMD14X1 and 14X2 4A fast blow (I
2
t <20A
2
s)
SPMD14X3 and 14X4 6.3A fast blow (I
2
t <100A
2
s)
SPMD16X1 and 16X2 4A fast blow (I
2
t <20A
2
s)
SPMD16X3 and 16X4 6.3A fast blow (I
2
t <100A
2
s)
Unidrive SPMC/U external 24V supply requirements
Nominal voltage: 24V
Minimum voltage: 23V
Maximum voltage: 28V
Current drawn: 3A
Minimum start-up voltage: 18V
Recommended power supply: 24V, 100W, 4.5A
Recommended fuse:
4A fast blow (I
2
t <20A
2
s)
N
If the Unidrive SPM 24V power supply (CT part number 8510-0000) is
used to supply the Unidrive SPMA/D or SPMC/U fusing is not required.
14.1.4 Unidrive SPM 24V power supply
CT part number: 8510-0000
Current rating: 10A
Input voltage: 85 to 123 / 176 to 264Vac auto switching
Cable size: 0.5mm
2
(20AWG)
Fuse: 5A slow-blow from supply
14.1.5 Additional line reactors
Reactor current ratings
See section 6.2.3 Supplies requiring additional line reactance on
page 68.
The current rating of the line reactors should be as follows:
Continuous current rating:
Not less than the continuous input current rating of the drive
Repetitive peak current rating:
Not less than twice the continuous input current rating of the drive
14.1.6 Motor requirements
No. of phases: 3
Maximum voltage:
Unidrive SPM (200V): 240V
Unidrive SPM (400V): 480V
Unidrive SPM (690V): 690V
14.1.7 Temperature, humidity and cooling method
Ambient temperature operating range:
0°C to 50°C (32°F to 122°F).
Output current derating must be applied at ambient temperatures
>40°C (104°F).
Minimum temperature at power-up:
-15°C (5°F), the supply must be cycled when the drive has warmed
up to 0°C (32°F).
Cooling method: Forced convection
Maximum humidity: 95% non-condensing at 40°C (104°F)
14.1.8 Storage
-40
o
C (-40
o
F) to +50
o
C (122
o
F) for long term storage, or to +70°C
(158°F) for short term storage.
14.1.9 Altitude
Altitude range: 0 to 3,000m (9,900 ft), subject to the following conditions:
1,000m to 3,000m (3,300 ft to 9,900 ft) above sea level: de-rate the
maximum output current from the specified figure by 1% per 100m
(330 ft) above 1,000m (3,300 ft)
For example at 3,000m (9,900ft) the output current of the drive would
have to be de-rated by 20%.
14.1.10 IP Rating (Ingress Protection)
The Unidrive SPM is rated to IP20 pollution degree 2 (dry, non-
conductive contamination only) (NEMA 1). However, it is possible to
configure the drive to achieve IP54 rating (NEMA 12) at the rear of the
heatsink for through-panel mounting (some current derating is required,
and the fan requires changing on SPMC/U).
Part number Model
Maximum Losses
W
4401-0181 INL401
148
4401-0182 INL402
205
4401-0183 INL601
88
4401-0184 INL602
116
4401-0206 INL411
252
4401-0207 INL412
270
4401-0190 INL611
241
4401-0191 INL612
269
Part number Model
Maximum Losses
W
4401-0197 OTL401
113
4401-0198 OTL402
145
4401-0199 OTL403
122
4401-0200 OTL404
156
4401-0201 OTL601
63
4401-0202 OTL602
74
4401-0203 OTL603
61
4401-0204 OTL604
70
4401-0188 OTL411
71
4401-0189 OTL412
85
4401-0192 OTL413
83
4401-0186 OTL414
100
4401-0193 OTL611
74
4401-0194 OTL612
85
4401-0195 OTL613
88
4401-0196 OTL614
100
