Safety
Information
Introduction
Product
Information
System
configuration
Mechanical
Installation
Electrical
Installation
Getting
Started
Basic
parameters
Running
the motor
Optimization
SMARTCARD
operation
Onboard
PLC
Advanced
parameters
Technical
Data
Diagnostics
UL Listing
Information
62 Unidrive SPM User Guide
www.controltechniques.com Issue Number: 3
5.13 Electrical terminals
5.13.1 Location of the power and ground terminals
Figure 5-50 Locations of the power and ground terminals on Unidrive SPM
Master interface
SPMA SPMD SPMC/U
Relay terminals
3mm
Control terminals
2.5mm
8mm AF
8mm AF
M10 nut
17mm AF
M10 nut
17mm AF
2.5mm
M10 nut
17mm AF
M10 nut
17mm AF
2.5mm
M10 nut
17mm AF
M10 nut
17mm AF
2.5mm
11mm
Suitable for
M10 nut & bolt
AC IN
DC IN
AC IN
AC OUT AC OUT DC OUT
