290 Unidrive SPM User Guide
www.controltechniques.com Issue Number: 3
Table 15-2 Serial communications look-up table
No. Trip No. Trip No. Trip
1
UV 40 to 89 t040 to t089 182 C.Err
2
OV 90 UP div0 183 C.dAt
3
OI.AC 91 UP PAr 184 C.FULL
4
OI.br 92 UP ro 185 C.Acc
5
PS 93 UP So 186 C.rtg
6
Et 94 UP ovr 187 C.TyP
7
O.SPd 95 UP OFL 188 C.cPr
8
PS.10V 96 UP uSEr 189 EnC1
9
PS.24V 97 UP udF 190 EnC2
10
br.th 98 UP ACC 191 EnC3
11
tunE1 99 t099 192 EnC4
12
tunE2 100 193 EnC5
13
tunE3 101 t101 194 EnC6
14
tunE4 102 Oht4.P 195 EnC7
15
tunE5 103 OIbr.P 196 EnC8
16
tunE6 104 OIAC.P 197 EnC9
17
tunE7 105 Oht2.P 198 EnC10
18
tunE 106 OV.P 199 DESt
19
It.br 107 PH.P 200 SL1.HF
20
It.AC 108 PS.P 201 SL1.tO
21
O.ht1 109 OIdC.P 202 SL1.Er
22
O.ht2 110 Unid.P 203 SL1.nF
23
O.CtL 111 ConF.P 204 SL1.dF
24
th 112 to 160 t112 to t160 205 SL2.HF
25
thS 161 Enc11 206 SL2.tO
26
O.Ld1 162 Enc12 207 SL2.Er
27
O.ht3 163 Enc13 208 SL2.nF
28
cL2 164 Enc14 209 SL2.dF
29
cL3 165 Enc15 210 SL3.HF
30
SCL 166 Enc16 211 SL3.tO
31
EEF 167 Enc17 212 SL3.Er
32
PH 168 to 174 t168 to t174 213 SL3.nF
33
rS 175 C.Prod 214 SL3.dF
34
PAd 176 EnP.Er 215 SL.rtd
35
CL.bit 177 C.boot 216 t216
36
SAVE.Er 178 C.bUSY 217 to 232 HF17 to HF32
37
PSAVE.Er 179 C.Chg
38 t038 180 C.OPtn
39
L.SYnC 181 C.RdO
