Unidrive SPM User Guide 251
Issue Number: 3 www.controltechniques.com
13.16 Menu 18: Application menu 1
13.17 Menu 19: Application menu 2
13.18 Menu 20: Application menu 3
With software V01.07.00 and later, all menu 20 parameters are transferred to the SMARTCARD when a 4yyy transfer is performed. See section
11.2.1 Writing to the SMARTCARD on page 150 for more information.
Parameter
Range(
Ú) Default(Ö)
Type
18.01
Application menu 1 power-down
saved integer
-32,768 to +32,767 0 RW Bi NC PS
18.02 to
18.10
Application menu 1 read-only integer -32,768 to +32,767 0 RO Bi NC
18.11 to
18.30
Application menu 1 read-write integer -32,768 to +32,767 0 RW Bi US
18.31 to
18.50
Application menu 1 read-write bit OFF (0) or On (1)
0
RW Bit US
Parameter
Range(
Ú) Default(Ö)
Type
19.01
Application menu 2 power-down
saved integer
-32,768 to +32,767 0 RW Bi NC PS
19.02 to
19.10
Application menu 2 read-only integer -32,768 to +32,767 0 RO Bi NC
19.11 to
19.30
Application menu 2 read-write integer -32,768 to +32,767 0 RW Bi US
19.31 to
19.50
Application menu 2 read-write bit OFF (0) or On (1) 0 RW Bit US
Parameter
Range(
Ú) Default(Ö)
Type
20.01 to
20.20
Application menu 3 read-write integer -32,768 to +32,767 0 RW Bi NC
20.21 to
20.40
Application menu 3 read-write long
integer
-2
31
to 2
31
-1
0RWBiNC
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
