Figure 13-41 SM-I/O 24V Protected digital I/O logic diagram
Figure 13-42 SM-I/O 24V Protected relay logic diagram
??.??
Any
unprotected
parameter
??.??
X.25
x(-1)
X.15X.05
T7 digital input 5
T7 digital
input 5 state
T7 digital
input 5 invert
T7 digital input 5
destination
??.??
Any
unprotected
parameter
??.??
X.26
x(-1)
X.16X.06
T8 digital input 6
T8 digital
input 6 state
T8 digital
input 6 invert
T8 digital input 6
destination
??.??
Any
unprotected
parameter
??.??
X.27
x(-1)
X.17X.07
T9 digital input 7
T9 digital
input 7 state
T9 digital
input 7 invert
T9 digital input 7
destination
Relay 1
0.XX
0.XX
Key
Read-write (RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
The parameters are all shown at their default setting
Any bit or
integer
parameter
Relay 2
Any bit or
integer
parameter
