264 Unidrive SPM User Guide
www.controltechniques.com Issue Number: 3
Table 14-4 Maximum permissible continuous output current @ 50°C (122°F) ambient (SPMD drives in undocked condition)
N
For the definition of ambient temperature, see section 5.8.2 Enclosure ambient temperature on page 51.
N
An additional derating of 5% is required for parallel applications.
Table 14-5 Unidrive SPMC/U maximum permissible ratings
Table 14-3
Maximum permissible continuous output current @ 50°C (122°F) ambient (SPMD drives in docked condition)
Model
Normal Duty
Heavy Duty
Maximum permissible continuous output current (A) for
the following switching frequencies
Maximum permissible continuous output current (A)
for the following switching frequencies
3kHz 4kHz 6kHz 3kHz 4kHz 6kHz
SPMA14X1
191 190 148 180 158 122
SPMA14X2
198 181 138 190 158 116
SPMA16X1
98 81 59 98 81 59
SPMA16X2
98 81 59 98 81 59
SPMD12X1
172 157 120 156 135 100
SPMD12X2
208 189 145 190 158 116
SPMD12X3
244 222 170 224 186 137
SPMD12X4
282 256 196 262 218 160
SPMD14X1
172 157 120 163 135 100
SPMD14X2
208 189 145 190 158 116
SPMD14X3
244 222 170 224 186 137
SPMD14X4
282 256 196 262 218 160
SPMD16X1
114 93 67 100 82 59
SPMD16X2
122 102 75 121 101 75
SPMD16X3
138 117 86 129 108 80
SPMD16X4
138 117 85 137 110 77
Model
Normal Duty
Heavy Duty
Maximum permissible continuous output current (A) for
the following switching frequencies
Maximum permissible continuous output current (A)
for the following switching frequencies
3kHz 4kHz 6kHz 3kHz 4kHz 6kHz
SPMD12X1
172 157 120 156 135 100
SPMD12X2
208 189 145 190 158 116
SPMD12X3
244 222 170 224 186 137
SPMD12X4
305 265 200 270 230 170
SPMD14X1
172 157 120 163 135 100
SPMD14X2
208 189 145 190 158 116
SPMD14X3
244 222 170 224 186 137
SPMD14X4
305 265 200 270 230 170
SPMD16X1
121 99 71 100 86 62
SPMD16X2
135 114 85 125 108 81
SPMD16X3
154 127 95 137 115 86
SPMD16X4
157 133 100 155 129 97
NOTE
NOTE
Model
35°C (95°F) ambient temperature 40°C (104°F) ambient temperature 50°C (122°F) ambient temperature
Maximum AC
input current
A
Maximum DC
output current
A
Maximum AC
input current
A
Maximum DC
output current
A
Maximum AC
input current
A
Maximum DC
output current
A
SPMC/U1402 358 394 344 379 302 333
SPMC/U2402 2 x 325 2 x 359 2 x 312 2 x 345 2 x 278 2 x 307
SPMC/U1601 203 218 195 209 169 181
SPMC/U2601 2 x 180 2 x 192 2 x 173 2 x 185 2 x 152 2 x 163
