Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG 6-25
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
6
Software Menus
10.0000
ppm
Input
CO
10.0000
ppm
Output
CO
Flow 1 0.00 l/min
Specify how the measured gas concentration
values are displayed.
Component
Unit..
Precision: 0.123
Gas Name: CO
Range Tag Ch1-R1
Concentration 10.000 ppm
6.2.3.1.2.1 Display Component Setup Menu
6.2.3 Setup Menu
Congure the component´s measuring unit
6-26
Congure the precision of the displayed measu-
red value for this component.
Selectable options:
0. 0.1 0.12 0.123 0.1234
(means, the fraction part can be setup bet-
ween none and four digits).
Shows the current range tag
Specify the gas name for this component, to
show up on the measurement display.
Maximum length: 12 characters
The last line shows the current settings for
the selected channel, depending on the set-
tings above, and is updated if settings are
changed.
Multi-channel unit:
In SELECT COMPONENT, select the chan-
nel to be congured.
Multi-channel unit:
Press
left to enter SELECT COMPONENT,
to change the settings for another channel.
Setup..
Display..
Measurements..
Component..
Gas
name
Unit text
Label
Secondary
measurement
Fig. 6-2: Measurement Display Elements
