Emerson Process Management GmbH & Co. OHG1-16
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
1.5 X-STREAM XEGK: ½19 Inch Table-Top Unit
1.5 X-STREAM XEGK
This compact model for general purposes
can be tted with up to three measurement
channels in various combinations. Power is
supplied by an internal wide range power sup-
ply or a separate external power supply unit.
By default the units are congured for tabletop
use. A carrying handle is optional available
which makes it easy to take the instrument to
varying sampling points. For rack mounting a
XEGK is xed by screws located at the front
panel.
Connection to power supply
AC is supplied by an IEC chassis plug with
power switch and fuse holders. The internal
wide range power supply unit enables the
analyzers to be used worldwide. DC 24 V
power is supplied via a 3-pin socket at the
rear of the unit.
Interfaces
Electrical connections for interface signals are
provided via submin-D connectors, Ethernet
and USB connectors mounted on the rear
panel of the device
(
(
Fig. 1-8).
Detailed technical details on the various in-
terfaces can be found at 2-2. The con-
guration of the connectors are described in
Chapter 4 'Installation' and the software
settings in Chapter 6 'User interface and
software menus'.
Gas connections
Depending on the conguration of the unit
(number of measurement channels and serial
or parallel connection), sample and calibration
gases are fed into the unit via up to 8 tube
ttings mounted on the rear panel. Any free
tube ttings can be used for purging the de-
vice
to minimize interference from the ambient
atmosphere,
or
when measuring corrosive and/
or ammable gases.
