Emerson Process Management GmbH & Co. OHG 1-25
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
1.8 X-STREAM XEFD
1.8 X-STREAM XEFD: Cast Aluminum Flameproof Housing
The most obvious X-STREAM XEFD analyzer
feature is its ameproof housing ( Fig.
1-13 ). This enables its use in Ex-zone 1 ha-
zardous environments. With a protection type
of IP66/NEMA Type 4X and sturdy cast alu-
minum housing designed for wall-mounting, it
can also be used in other tough environments.
IPx6: In case of occasional ooding, e.g.
heavy seas, water shall not enter in harmful
quantities
IP6x: Protection against penetration by dust.
Live or internal moving parts are completely
protected.
Up to ve measuring channels in various com-
binations can be installed in the X-STREAM
XEFD. The physical components can optio-
nally be encased in a cover. This separate
volume can be held at a specic temperature
of up to 60 °C to minimize interference from
changes in external temperature.
Front panel
The analyzer’s display is
protected by an
impact tested glass for enhanced protection
against breakage in harsh environments.
Electrical connections
Electrical connections are made via internal
screw-type terminals; the corresponding
cables are fed through cable inlets on the un-
derside of the unit into the housing (
Fig.
1-14 ). The front of the unit opens downwards
once the screws located on the surrounding
ange are removed
.
Connection to power supply
Mains power is connected via screw-type
terminals with integrated fuses, located in
the front right-hand area of the housing. The
internally mounted wide range power supp-
ly unit ensures, the analyzers can be used
worldwide.
Interface signals
Up to two digital I/O cards may be installed,
where terminal strip for the rst digital I/O card
is marked "X4.1" while the second is "X4.2"
on a label near the terminals.
Detailed technical details on the various inter-
faces can be found at
2-2. The congu-
ration of the screw-type terminal adapters are
described in Chapter 4 'Installation'and
the software settings in Chapter 6 'User
interface and software menus'.
Gas connections
Depending on the conguration of the unit
(number of channels, series or parallel pi-
ping), up to eight ame arresters are provi-
ded for the supply of sample and calibration
EXPLOSION HAZARD
The special conditions for installing and operating analyzers in hazardous
areas are not covered by this manual!
Read the separate instruction manuals shipped together with instruments
intended to be installed in hazardous areas!
1
Technical Description
