Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG6-72
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
6.2.3 Setup Menu
Node: System
Inputn Function
Option Description
None Not used
Zero All
Carry out the selected cali-
bration procedure, or cancel
any ongoing calibration
Span All
Zero&Span All
Cancel All
ProgSequ
Perform calibration sequ.
Blowback Activate blowback
CalCheckMod
Perform calibration check
Failure
The input signal activates
the related analyzer NAMUR
status
OffSpec
MaintRequ
FctCheck
Pump1…2 Activate related pump
ExtStatus1…8
Input signal is assigned the
selected alarm signal
Datalogger Start data logger
Node: Ch1…Ch5
Inputn Function
Option Description
None Not used
ZeroCal
Carry out the selected cali-
bration procedure, or cancel
any ongoing calibration
SpanCal
ZeroSpanCal
Cancel
Range1…4 Activate the selected range
Failure
The input signal activates
the related channel NAMUR
status
OffSpec
MaintRequ
FctCheck
SampleGas
Open related valveZeroGas
SpanGas1…4
AllClosed Close all valves
Blowback Activate blowback
ConcAlaOff Switch off concentration
alarms monitoring
ConcAlaOn Switch on concentration
alarms monitoring
Menu pages 4 ... 6 (titled 'Digital inputs
(X4.2)') enable to congure inputs 8 ... 14 on
a second expansion board ('X4.2' in the menu
title refers to the instrument´s I/O connector
X4.2).
 Digital Inputs (X4.2) 1of3
Input8 Node: System
Input8 Function: ExtFail
Input8 Edge: Up
Input9 Edge: Up
Input9 Node: Ch3
Input9 Function: Range4

Input10 Node:
System
Input10 Function: ExtFail
Input10 Edge: Up
Input11 Node: System
Input11 Function: ExtFail
Input11 Edge: Up
Input12 Node: Ch1
Input12 Function: Range1
Input12 Edge:
Down
 Digital inputs (X4.2) 3of3
Input13 Node: System
Input13 Function: FctCheckl
Input13 Edge: Rising
Input14 Node: Ch3
Input14 Function: Range4
Input14 Edge: Trailing
Tab. 6-4: Digital Input Signals
