Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG 6-69
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
6
Software Menus
6.2.3 Setup Menu
Node: System (related to analyzer)
Option Description
Off Switched off
On Switched on
Heartbeat
Status changes every second
(test mode)
Any Failure
Any failure, off-spec, main-
tenance request or function
check status is set
1)
Any OffSpec
Any MaintRequ
Any FctCheck
Any Calibrating
Any calibration, zero or span
calibration is ongoing
Any Zeroing
Any Spanning
Any Zero Failed
A zero or span calibration
failed
Any Span Failed
Any Range Low
Any measured value exceeds
a current range
Any Range High
Any ConcAlarm
Any channel triggered an
alarm of the selected type
2)
Any AvgAlarm
Any TempAlarm
Any PressAlarm
Any FlowAlarm
V1…V20 Drive an external valve
Pump1…2 Drive an external pump
Ext Status1…8 An alarm is triggered
PLC Result1…10 Status of related PLC result
CalcA Rslt LoLo
The result of calculatorA ex-
ceeds the selected limit
2)
CalcA Rslt Lo
CalcA Rslt Hi
CalcA Rslt HiHi
CalcB Rslt LoLo
....
CalcD Rslt HiHi
Similar to CalcA, but for calcu-
latorsB…D
2)
Ain1..
..LoLo, ..Lo,
..Hi, ..HiHi
An alarm of the selected type
is triggered
by Analog Input 1
or 2
2)
Ain2..
..LoLo, ..Lo,
..Hi, ..HiHi
Node: Ch1…Ch5 (related to channel)
Option Description
Off Switched off
On Switched on
Heartbeat
Status changes every se-
cond (test mode)
Failure
A channel specic failure,
off-spec, maintenance
request or function check
status is set
1)
Off-Spec
MaintRequ
FctCheck
Calibrating
The channel is calibrating,
zeroing or spanning
Zeroing
Spanning
Zero Failed
The selected procedure
failed
Span Failed
Range Underow
Measured value exceeds
current range
Range Overow
Range 1…4 The selected range is active
Conc LoLo
A concentration alarm of the
selected type is triggered
2)
Conc Lo
Conc Hi
Conc HiHi
Average..
..LoLo, ..Lo,
..Hi, ..HiHi
A concentration average
alarm of the selected type is
triggered
2)
Temperature..
..LoLo, ..Lo,
..Hi, ..HiH
A temperature alarm of the
selected type is triggered
2)
Pressure..
..LoLo, ..Lo,
..Hi, ..HiH
A pressure alarm of the se-
lected type is triggered
2)
Flow..
..LoLo, ..Lo,
..Hi, ..HiH
A ow alarm of the selected
type is triggered
2)
Tab. 6-3: Digital Output Signals
1)
If assigned, the output is automatically congured
Failsafe
2)
Parameter "Alarms Output Failsafe" can be used to
manually congure Failsafe all outputs assigned to
the same type of option (indexed with
2)
). 6-80
