Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG 1-5
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
1.2 Conguration of Gas Lines
1.2 Conguration of Gas Lines
1.2.1 Materials Used
Various materials are available to allow the
analyzer to be customized to your needs.
The materials used are selected based on
the characteristics of the sample gas, e.g.
diffusion rate, corrosiveness, temperature and
pressure. Among those available are Viton
®
,
PFA and stainless steel.
1.2.2 Safety Filter
The analyzers are generally tted with an
internal stainless-steel lter. This lter is not
a replacement for any dust lter in the prepa-
ration of the gas, but represents a last line of
defence.
1.2.3 Gas Inlets and Outlets
Rackmounted and tabletop devices are tted
with PVDF inlets and outlets (ø 6/4 mm) as
standard. Alternatively, Swagelok™ or stain-
less steel ttings (ø 6/4 mm or
1
⁄4 in).
Wall-mounted eld housings are supplied
with Swagelok™ or stainless steel ttings (ø
6/4 mm or
1
⁄4 in).
Other materials available on request.
X-STREAM XEFD units are always supplied
with ame arrestors and stainless steel ttings
(ø 6/4 mm or
1
⁄4 in).
Fieldhousings and 19 in analyzers provide up
to 8 gas ttings, so if featuring ve channels,
this requires at least two channels in serial
tubing.
1.2.4 Tubing
Unless otherwise specied, the analyzers
are supplied with Viton
®
or PVDF piping
(ø 6/4 mm or
1
⁄4 in). Other materials (e.g.
stainless steel) can be used, depending on
the application.
1.2.5 Infallible Containments
Infallible containments are gas lines which,
due to their design, can be regarded as per-
manently technically tight. This is achieved
by, for example, welded joints, or metallically
sealing joints (e.g. tap connectors and bin-
ders), providing they are seldom disconnec-
ted. Gas lines congured in this manner can
be used for measuring noxious, ammable
and explosive gases. At the time of going to
press, infallible containments are available
for thermal conductivity analysis (TC) only.
Further information about infallible contain-
ments can be found in the separate instruction
manual supplied with these units.
Infallible containments do not
render it unnecessary to regu-
larly test for leaks, e.g. following
lengthy breaks in service, sub-
stantial alterations, repairs and
modications.
Read the separate instruction
manual giving detailed instruc-
tions on the conguration, ope-
ration and maintenance of units
fitted with infallible contain-
ments.
1
Technical Description
