Emerson Process Management GmbH & Co. OHG 1-23
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
1.7 X-STREAM XEXF Field Housings
1 Screw-type terminals for signal cables
2 Power line lter
3 Cable glands
4 Power supply terminals with integrated fuses
5 Ethernet and USB connectors
Fig. 1-12: X-STREAM XEF - Power Supply and Signal Terminals
(shown with front
panel removed)
1 32 45
Note!
In case of XDF, the terminals and
connectors are located at the upper
compartment, while physical compo-
nents and gas ttings are in the lower
compartment.
1
Technical Description
