Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG1-28
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
1.8 X-STREAM XEFD
1 Terminals for signal cables (shown fully populated)
2 Power line lter
3 Cable inlets for power and signal cables
4 Power supply terminals with integrated fuses
5 Ethernet and USB connectors
Fig. 1-15: X-STREAM XEFD - Terminals
(shown with front
panel removed)
1 42 35
