Emerson Process Management GmbH & Co. OHG 2-19
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
2
Technical Data
Fig. 2-13: X-STREAM XEFD - Dimensions
Transport lugs to be removed after installation
Cable inlets
(enclosure threads; M20 x 1.5)
Flame arrestors with gas ttings
(enclosure threads: M18 x 1.5)
Eyebolt detail
All dimensions in mm
[inches in brackets]
2.2.4 Model-Specic Technical Data: X-STREAM XEFD
2.2.4 X-STREAM XEFD: Flameproof Housing
