Epson Stylus Pro 9900 User Manual

Epson Stylus Pro 7900/7910/9900/9910 User’s Guide
Paper Handling
36
Removing the roll paper
A
Make sure the printer is turned on.
B
Open the roll paper cover.
C
Press the button to release the paper
presser.
The roll paper is rewound automatically if
the printer state is after the paper cut but in
the READY state. However, when using the
optional Auto Take-up Reel Unit, the
printer does not rewind the roll paper.
Rewind the roll paper manually, if it is not
automatically done.
Note:
We recommend that you remove the roll paper from
the printer after printing. If the paper roll is left in the
printer, the roller for securing the paper may leave a
mark on the surface of the paper.
Note:
When you are not using the roll paper, wrap it
using the optional roll paper belt.

Epson Stylus Pro 9900 Specifications

General

Color	Yes
Maximum resolution	2880 x 1440 DPI
Media thickness	0.08 - 1.50 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll width	1118 mm
Display	LCD
Internal memory	64 MB
Country of origin	China
Drive device, buffer size	256 MB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Fast Ethernet
Compatible operating systems	Microsoft Windows 2000, XP, XP 64-bit, Vista, MAC OSX 10.x.x
Power requirements	AC 100-240V 50/60Hz
Power consumption (active)	80 W
Power consumption (standby)	1 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	2040 mm
Package width	815 mm
Package height	1080 mm
Package weight	193053 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Dimensions (WxDxH)	1702 x 678 x 1196 mm
