Epson Stylus Pro 7900/7910/9900/9910 User’s Guide
Maintenance
77
E
Check if there are missing dots on the
nozzle check pattern.
If there are no missing dots, click Finish.
If there are missing dots, click Clean.
After printing a nozzle check pattern, make
sure that the nozzle check pattern printing
is complete before starting to print your
data or cleaning the print head.
Checking the print head nozzles
using the printer’s control panel
A
Make sure that roll paper or A4/Letter size
or larger is loaded in the printer.
Select the correct paper source according to
the paper.
See “Paper Handling” on page 30
B
Press the button to enter the Menu
mode.
C
Press the / button to display TEST
PRINT, and then press the button.
D
Press the / button to display NOZZLE
CHECK, and then press the button.
E
Press the button to start printing a
nozzle check pattern.
F
Check the nozzle check pattern.
Good
There are no missing dots so the nozzles are
not clogged.
Bad
There are missing dots so the nozzles are
clogged. Perform head cleaning.
See “Head cleaning” on page 78

Epson Stylus Pro 9900 Specifications

General

Color	Yes
Maximum resolution	2880 x 1440 DPI
Media thickness	0.08 - 1.50 mm
Maximum print size	A0 (841 x 1189 mm)
Maximum roll width	1118 mm
Display	LCD
Internal memory	64 MB
Country of origin	China
Drive device, buffer size	256 MB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Fast Ethernet
Compatible operating systems	Microsoft Windows 2000, XP, XP 64-bit, Vista, MAC OSX 10.x.x
Power requirements	AC 100-240V 50/60Hz
Power consumption (active)	80 W
Power consumption (standby)	1 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	2040 mm
Package width	815 mm
Package height	1080 mm
Package weight	193053 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Dimensions (WxDxH)	1702 x 678 x 1196 mm
