Layout Adjustment
141
Copy
3
for the length (Y), in 1 mm increments. To help you specify values, use the scales attached
on the upper and left edges of the document glass.
z
When the document is loaded in the document feeder, the base point in the Y (length) direction is the center
of the edge. If you specify 100 mm, the scan length will be from 50 mm above to 50 mm below the center of
the document.
Mixed Size Originals (Scanning Different Size Documents
Simultaneously)
You can scan documents of various sizes simultaneously and make copies of the
corresponding sizes or of one selected size. To use this feature, load the documents in the
document feeder.
z
Load documents in landscape orientation. However, always load A5 documents in portrait orientation.
z
When loading B5 documents together with A3 documents loaded in landscape orientation or A4 documents
loaded in portrait orientation, load B5 documents in portrait orientation.
z
If the top left corners of the documents are not aligned properly, the documents may not be scanned
correctly.
z
The recommended document size combinations are A4 portrait and A3 landscape, or B5 portrait and B4
landscape. If another combination of document sizes is used, the documents can be fed at an angle and may
not be copied properly.
z
This feature does not appear for some models. An optional component is required. For more information,
contact our Customer Support Center.
1 Select [Mixed Size Originals].
2 Select [On].
îš„ Off
Select this option when copying documents of the same size.
To Next Page
