2. OPERATIONAL OVERVIEW
2-9
Guide Box Shows or hides the guide box, which provides range and bearing measurement
between waypoints when creating a route.
Note: The distance between waypoints can be calculated by the [Rhumbline] or
[Great Circle] method. Open the [NAV Tools] menu, select [Geometry], then se-
lect desired method.
Manage
Data
Manages routes and user charts. Route imports, exports, deletes routes. User
Chart deletes user charts. Data Import imports routes and user charts.
Common bar
Chart INFO Provides chart information.
Chart Legend shows chart information for ship’s position when own ship is at the
screen center.
Viewing Dates sets Display Date and Update Review dates.
Chart 1 displays an overview of the ECDIS chart symbols.
DISP SET shows the [Basic Setting] dialog box, [Chart Display] menu, [Symbol Display]
menu, [Chart Alert] dialog box. TWO DISP splits the screen in two, vertically or
horizontally, in the Voyage navigation mode. NtoM shows, hides the NtoM over-
lay. Keyboard shows, hides the software keyboard.
Log Displays Update log (ENC, ARCS, C-MAP), Event log (user event, POSN event)*,
NAV log (Voyage, Details, Chart Usage), Target log (Danger Target), and Route
Transfer log. *Voyage navigation and Voyage planning modes
Selects a color palette, day, dusk or night.
• Adjusts the brilliance of the monitor.
• Adjusts the backlighting of the control unit.
MOB Inscribes the MOB (ManOverBoard) mark.
Takes a screenshot.
Restores the previous condition in route and user chart creation.
Button Description
