3. HOW TO MANAGE CHARTS
3-20
3.15 Catalog of Chart Cells
A catalog is used to view graphical coverage of the charts stored in your SSD. Avail-
able charts are displayed showing their border limits. Note that sometimes the real
coverage of the charts may be considerably less than the declared limits of it.
To display the catalog, get into the Chart maintenance mode then click the [Manage
Charts] button on the InstantAccess bar
™
. The [Filter] window lets you choose what
to display. Check or uncheck items as appropriate.
1) Chart Type
ENC: Display ENC charts.
ARCS: Display ARCS charts.
C-MAP: Display C-MAP charts.
2) Availability
Display available or unavailable charts.
3) License
Valid: Cell with valid license.
Missing/Expired: Cell with missing or expired license.
Valid + Missing/Expired: Display cell regardless of license.
Uncheck both: Hide all cells.
4) Dynamic License
Display DL or non-DL charts.
