Garmin aera 660 Pilot’s Guide
190-02017-20 Rev. E
Appendix D
177
Overview Navigation Flight Planning Hazard Avoidance Additional Features Appendices Index
Securing the cable on the top of the yoke mount:
1) Remove the screws securing the cable clamp.
2) Orient the cable and secure the clamp with the screws.
Cable Clamp
Removing the yoke mount from the yoke shaft (or control arm):
1) Disconnect the cable connectors from the aircraft.
2) Loosen the clamp by turning the Clamp Adjustment Knob until the clamp
assembly can be easily removed from the yoke shaft or control arm.
CONNECTING TO A GARMIN VHF COMM RADIO
The aera 660 can also output frequency data to a Garmin aviation radio. For
additional information refer to the applicable installation manual. Currently the
following models are supported:
s SL30 NAV/COMM s GNC 255
s SL40 COMM s GTR 200
s GTR 225
NOTE: For additional information refer to the SL30 NAV/COMM, SL40 COMM,
GTR 225, GNC 255, or GTR 200 installation manual.
CAUTION: This interface does not have an FAA installation airworthiness
approval. If any tuning or operational abnormalities are encountered with the
SL30 nav/comm, SL40 comm, GTR 225, GNC 255, or GTR 200, disconnect the
aera 660 from the applicable tuning interface.

Garmin AERA 660 Specifications

General

Display Resolution	480 x 800 pixels
Touchscreen	Yes
Battery Life	Up to 4 hours
Voltage Range	10-35 V
Display Type	WVGA color TFT
Connectivity	Bluetooth
Preloaded Maps	Yes
Weather Updates	Yes
Traffic Updates	No
Receiver Type	GPS/GLONASS
Operating Temperature	-4°F to 131°F (-20°C to 55°C)
Weather Support	Yes
Traffic Support	No
