GEK-106310AB F650 Digital Bay Controller 5-3
5 SETTINGS 5.2 PRODUCT SETUP
5
5.2PRODUCT SETUP 5.2.1 COMMUNICATION SETTINGS
5.2.1.1 SERIAL PORTS
Baud rate and parity for COM1 and COM2 serial communication ports.
Table 5–2: SERIAL PORTS SETTINGS
5.2.1.2 NETWORK (ETHERNET)
Ethernet communication parameters for COM3. Two different Ethernet addresses can be used, but the first IP always has
to be set as the second IP Address is an Alias. The ModBus Slave address used by Ethernet ports is the one set for COM2.
Table 5–3: NETWORK SETTINGS
5.2.1.3 MODBUS PROTOCOL
ModBus Slave Addresses for serial and Ethernet communication and the ModBus port number used for ModBus TCP/IP.
For more detailed information go to appendix B in this manual.
Table 5–4: MODBUS PROTOCOL SETTINGS
PRODUCT SETUP > COMMUNICATION SETTINGS >SERIAL PORTS
Name Default Value Step Range
COM1 Baud Rate 19200 N/A [300 : 115200]
COM2 Baud Rate 19200 N/A [300: 115200]
COM1Parity NONE N/A [NONE:ODD:EVEN]
COM2Parity NONE N/A [NONE:ODD:EVEN]
PRODUCT SETUP > COMMUNICATION SETTINGS >NETWORK (ETHERNET) NETWORK
(ETHERNET)1 > NETWORK (ETHERNET)2
Name Default Value Step Range
IP Address Oct1 0 N/A [0: 255]
IP Address Oct2 0 N/A [0: 255]
IP Address Oct3 0 N/A [0: 255]
IP Address Oct4 0 N/A [0: 255]
Netmask Oct1 0 N/A [0: 255]
Netmask Oct2 0 N/A [0: 255]
Netmask Oct3 0 N/A [0: 255]
Netmask Oct4 0 N/A [0: 255]
Gateway IP Oct1 0 N/A [0: 255]
Gateway IP Oct2 0 N/A [0: 255]
Gateway IP Oct3 0 N/A [0: 255]
Gateway IP Oct4 0 N/A [0: 255]
PRODUCT SETUP > COMMUNICATION SETTINGS >MODBUS PROTOCOL
Name Default Value Step Range
ModBus Address COM1 254 1 [1 : 255]
ModBus Address COM2 254 1 [1 : 255]
ModBus Port Number 502 1 [0 : 65535]
