GE F650 User Manual

C-14 F650 Digital Bay Controller GEK-106310AB
C.5 DNP CONFIGURATION EXAMPLES APPENDIX C
C
C.5.2 EXAMPLE OF CUSTOM BINARY INPUT POINTS MAP
POINT
INDEX
NAME/DESCRIPTION
0 CONT_IP_F_CC1(CC1)
1 CONT_IP_F_CC2(CC2)
2 CONT_IP_F_CC3(CC3)
3 CONT_IP_F_CC4(CC4)
4 CONT_IP_F_CC5(CC5)
5 CONT_IP_F_CC6(CC6)
6 CONT_IP_F_CC7(CC7)
7 CONT_IP_F_CC8(CC8)
8 PH IOC1 HIGH A PKP
9 PH IOC1 HIGH B PKP
10 PH IOC1 HIGH C PKP
11 PH IOC1 LOW A PKP
12 PH IOC1 LOW B PKP
13 PH IOC1 LOW C PKP
14 GROUND IOC1 PKP
15 NEUTRAL IOC1 PKP
16 CONT OP_F_01
17 CONT OP_F_02
18 CONT OP_F_03
19 CONT OP_F_04
20 CONT OP_F_05
21 CONT OP_F_06
22 CONT OP_F_07
23 CONT OP_F_08
POINT
INDEX
NAME/DESCRIPTION
24 Not Configured
25 Not Configured
26 Not Configured
27 Not Configured
28 Not Configured
29 Not Configured
30 Not Configured
31 Not Configured
32 CONT_IP_F_CC13 (CC13)
33 CONT_IP_F_CC14(CC14)
34 CONT_IP_F_CC15(CC15)
35 CONT_IP_F_CC16(CC16)
36 Not Configured
37 Not Configured
38 Not Configured
39 Not Configured
40 Not Configured
