11 APPLICATION EXAMPLES 11.1 EXAMPLE 1: COMMUNICATION & PROTECTION SETTINGS PROCEDURE

11 APPLICATION EXAMPLES 11.1EXAMPLE 1: COMMUNICATION & PROTECTION SETTINGS PROCEDURE

11.1.1 DESCRIPTION OF THE EXERCISE

The requirements for this setting exercise are:

Communicate the relay via serial cable or Ethernet 10/100 Base T cable using EnerVista 650 Setup program.

Set some Phase Time Overcurrent protection function to operate at 5A, Inverse curve IEC, Dial 0.1

Set some Output contact on board F to be operated and sealed by the operation of the phase TOC.

Set some LED to show the operation of the phase TOC

Set some Operation to reset the output contact after dropout of the phase TOC since the front F1 pushbutton.

Set some Oscillography channel to record the pickup of phase TOC and output contact closing action.

To test the operation of this Phase Time Overcurrent protection

11.1.2 PROCEDURE TO COMMUNICATE WITH THE RELAY

This procedure describes the connection between any Laptop and some F650 relay using the EnerVista 650 SETUP

program

For any one of these connections check first the communication parameters as follows:

Serial Communication (RS232 or USB front port of the relay)

With the ESC key check on the main front screen the serial communication parameters (Baud rate, parity, data bits, stop bit

and ID number).

Connect the serial cable PC-F650

Open the EnerVista 650 SETUP program in the PC and under Communication  Computer menu check that the serial

communication parameters displayed are the same read in the front of the relay. Check also that:

Control Type is set to No Control Type

Startup Mode is set to Communicate with relay

Click ON key.

Ethernet LAN (10/100 Base T rear port of the relay)

In the Laptop choose My PC-Control Panel-Network-Protocols-Protocol TCP/IP-Advance and set in IP Address

screen the following:

IP Address 192.168.37.126

Netmask 255.255.255.0

In the front of F650 go to the Main Settings screen.

choose Change Settings .

Choose Comm Settings and press down the rotating knob or down key.

Choose Network 0 . It will be displayed IP Address OCT 1 and set it according to the following table:
