GEK-106310AB F650 Digital Bay Controller 6-35
6 ACTUAL VALUES 6.4 INPUTS / OUTPUTS
6
6.4INPUTS / OUTPUTS
Digital inputs and outputs are located in the same board. Depending on the relay model, the number of inputs and outputs
will vary.
6.4.1 CONTACT INPUTS
Actual > Inputs/Outputs > Contact inputs > Board X (being X the corresponding board in each case).
On the inputs screen, the LED associated to the activated input will light up in green, if an input is not activated, the LED will
not light up. The “Board X Status” LED indicates the status of the board; it will be lit up if the board is correct and the
communication or the Relay model is appropriate.
Table 6–46: CONTACT INPUTS ACTIVATION SIGNALS
CONTACT INPUTS TYPE 1 CONTACT INPUTS TYPE 2 CONTACT INPUTS TYPE 4 CONTACT INPUTS TYPE 5
CONT IP_X_CC1 (CC1) CONT IP_X_CC1 (CC1) CONT IP_X_CC1 (CC1) CONT IP_X_CC17 (CC17) CONT IP_X_CC1 (CC1)
CONT IP_X_CC2 (CC2) CONT IP_X_CC2 (CC2) CONT IP_X_CC2 (CC2) CONT IP_X_CC18 (CC18) CONT IP_X_CC2 (CC2)
CONT IP_X_CC3 (CC3) CONT IP_X_CC3 (CC3) CONT IP_X_CC3 (CC3) CONT IP_X_CC19 (CC19) CONT IP_X_CC3 (CC3)
CONT IP_X_CC4 (CC4) CONT IP_X_CC4 (CC4) CONT IP_X_CC4 (CC4) CONT IP_X_CC20 (CC20) CONT IP_X_CC4 (CC4)
CONT IP_X_CC5 (CC5) CONT IP_X_CC5 (CC5) CONT IP_X_CC5 (CC5) CONT IP_X_CC21 (CC21) CONT IP_X_CC5 (CC5)
CONT IP_X_CC6 (CC6) CONT IP_X_CC6 (CC6) CONT IP_X_CC6 (CC6) CONT IP_X_CC22 (CC22) CONT IP_X_CC6 (CC6)
CONT IP_X_CC7 (CC7) CONT IP_X_CC7 (CC7) CONT IP_X_CC7 (CC7) CONT IP_X_CC23 (CC23) CONT IP_X_CC7 (CC7)
CONT IP_X_CC8 (CC8) CONT IP_X_CC8 (CC8) CONT IP_X_CC8 (CC8) CONT IP_X_CC24 (CC24) CONT IP_X_CC8 (CC8)
CONT IP_X_CC9 (Va_COIL1) CONT IP_X_CC9 (CC9) CONT IP_X_CC9 (CC9) CONT IP_X_CC25 (CC25) CONT IP_X_CC9 (CC9)
CONT IP_X_CC10 (Vb_COIL1) CONT IP_X_CC10 (CC10) CONT IP_X_CC10 (CC10) CONT IP_X_CC26 (CC26) CONT IP_X_CC10 (CC10)
CONT IP_X_CC11 (Va_COIL2) CONT IP_X_CC11 (CC11) CONT IP_X_CC11 (CC11) CONT IP_X_CC27 (CC27) CONT IP_X_CC11 (CC11)
CONT IP_X_CC12 (Vb_COIL2) CONT IP_X_CC12 (CC12) CONT IP_X_CC12 (CC12) CONT IP_X_CC28 (CC28) CONT IP_X_CC12 (CC12)
CONT IP_X_CC13 (O7_SEAL) CONT IP_X_CC13 (CC13) CONT IP_X_CC13 (CC13) CONT IP_X_CC29 (CC29) CONT IP_X_CC13 (CC13)
CONT IP_X_CC14 (O8_SEAL) CONT IP_X_CC14 (CC14) CONT IP_X_CC14 (CC14) CONT IP_X_CC30 (CC30) CONT IP_X_CC14 (CC14)
CONT IP_X_CC15 (SUP_COIL1) CONT IP_X_CC15 (CC15) CONT IP_X_CC15 (CC15) CONT IP_X_CC31 (CC31) CONT IP_X_CC15 (CC15)
CONT IP_X_CC16 (SUP_COIL2) CONT IP_X_CC16 (CC16) CONT IP_X_CC16 (CC16) CONT IP_X_CC32 (CC32) CONT IP_X_CC16 (CC16)
BOARD X STATUS BOARD X STATUS BOARD X STATUS BOARD X STATUS
