GEK-106310AB F650 Digital Bay Controller 6-9
6 ACTUAL VALUES 6.2 STATUS
6
6.2.3.9 POWER
Forward Power and directional power elements
These functions may have several applications, for example, small generating plants connected to the power system, to
limit the supplied power and not to exceed its rated capacity.
If programmed conditions for any of the three elements are met, the corresponding LEDs will light up.
This screen shows the activation of all power elements available in the F650. It can be accessed from the menu: Actual>
Status > Protection >Power, and it includes the following signaling LEDs.
Table 6–12: POWER ACTUAL VALUES
FORWARD POWER ACTUAL VALUES DIRECTIONAL POWER ACTUAL VALUES WATTMETRIC GROUND FAULT
ACTUAL VALUES
FWD PWR1 STG1 PKP DIR PWR1 STG1 PKP 32N1 HIGH PKP
FWD PWR1 STG1 OP DIR PWR1 STG1 OP 32N1 HIGH OC PKP
FWD PWR1 STG2 PKP DIR PWR1 STG2 PKP 32N1 HIGH OP
FWD PWR1 STG2 OP DIR PWR1 STG2 OP 32N2 HIGH PKP
FWD PWR2 STG1 PKP DIR PWR1 STG PKP 32N2 HIGH OC PKP
FWD PWR2 STG1 OP DIR PWR1 STG OP 32N2 HIGH OP
FWD PWR2 STG2 PKP DIR PWR2 STG1 PKP 32N3 HIGH PKP
FWD PWR2 STG2 OP DIR PWR2 STG1 OP 32N3 HIGH OC PKP
FWD PWR3 STG1 PKP DIR PWR2 STG2 PKP 32N3 HIGH OP
FWD PWR3 STG1 OP DIR PWR2 STG2 OP 32N1 LOW PKP
FWD PWR3 STG2 PKP DIR PWR2 STG PKP 32N1 LOW OC PKP
FWD PWR3 STG2 OP DIR PWR2 STG OP 32N1 LOW OP
DIR PWR3 STG1 PKP 32N2 LOW PKP
DIR PWR3 STG1 OP 32N2 LOW OC PKP
DIR PWR3 STG2 PKP 32N2 LOW OP
DIR PWR3 STG2 OP 32N3 LOW PKP
DIR PWR3 STG PKP 32N3 LOW OC PKP
DIR PWR3 STG OP 32N3 LOW OP
WATTMETRIC GROUND FAULT
POWER MEASUREMENT ACTUAL
VALUES
32N1 HIGH POWER
32N2 HIGH POWER
32N3 HIGH POWER
To Next Page
