GE F650 User Manual

2-30 F650 Digital Bay Controller GEK-106310AB
2.4 TECHNICAL SPECIFICATIONS 2 PRODUCT DESCRIPTION
2
2.4.12 ENVIRONMENTAL CHARACTERISTICS
2.4.13 PACKAGING AND WEIGHT
2.4.14 TYPE TESTS
Type test report available upon request.
F650 has been designed to comply with the highest existing requirements. More specifically, UNIPEDE recommendations
for high voltage substations are followed, even if for most applications such high classes are not required.
The relay complies with ANSI C37.90 standards, and has been designed to comply with international standards.
2.4.15 APPROVALS
Operating temperature:
- 10°C to + 60°C
Storage temperature:
- 40°C to + 80°C
Humidity (non condensing): 95%
Altitude Up to 2000 m
Installation category II
Net weight: 5 kg
Packaged: 6 kg
Package dimensions: 30x40x40 cm (DxWxH)
CATEGORY STANDARD CLASS TEST
EMC IEC 61000-4-1 IEC 60255-22-1 III Oscillatory waves immunity
IEC 61000-4-2 IEC 60255-22-2 IV Electrostatic discharge immunity test
IEC 61000-4-3 IEC 60255-22-3 III Radiated electromagnetic field disturbance test
IEC 61000-4-4 IEC 60255-22-4 IV Electrical fast transient
IEC 61000-4-5 IEC 60255-22-5 IV Surge immunity test
IEC 61000-4-6 IEC 60255-22-6 III Conducted electromagnetic field disturbance test
IEC 61000-4-8 EN 61000-4-8 IV Power frequency magnetic field immunity
ENV50204 III Radiated electromagnetic field disturbance test –
1800MHz MHz.
EMC Emisivity IEC 60255-25 EN 61000-6-4 A Conducted and radiated emissions
Product IEC 60255-5 2 kV Insulation resistance – dielectric test
IEC 60255-5 6kV .5J Impulse test
IEC 60255-11 100 ms Power supply Voltage dips/interruptions/variations:
Mechanical IEC 60255-21-1 I Vibration test (sinusoidal)
IEC 60255-21-2
IEC 60255-21-3
I
II
Shock and bump
Seismic
ISO9001 Registered system.
CE marking: Meets the CE standards relevant for protections.
UL 508 Certified
