GE F650 User Manual

GEK-106310AB F650 Digital Bay Controller 6-3
6 ACTUAL VALUES 6.2 STATUS
6
6.2.3 PROTECTION
6.2.3.1 PROTECTION BLOCKS
(Actual > Status > Protection > Protection Blocks)
This screen shows the entire protection element blocks available. If the protection element is blocked, the green LED
located on the right side of the text will light up and will remain lit as long as the element remains blocked.
Protection elements block signals are configured at Setpoint > Relay Configuration > Protection Elements.
Table 6–4: PROTECTION ELEMENTS BLOCK
IOC BLOCK SIGNALS TOC BLOCK SIGNALS DIRECTIONAL BLOCKS VOLTAGE BLOCKS
PH IOC1 HIGH A /B / C BLK PH TOC1 HIGH A /B /C BLK PHASE DIR1 BLK INP PHASE UV1 BLOCK
PH IOC2 HIGH A /B / C BLK PH TOC2 HIGH A /B /C BLK PHASE DIR2 BLK INP PHASE UV2 BLOCK
PH IOC3 HIGH A /B / C BLK PH TOC3 HIGH A /B /C BLK PHASE DIR3 BLK INP PHASE UV3 BLOCK
PH IOC1 LOW A /B / C BLK PH TOC1 LOW A /B /C BLK NEUTRAL DIR1 BLK INP PHASE OV1 BLOCK
PH IOC2 LOW A /B / C BLK PH TOC2 LOW A /B /C BLK NEUTRAL DIR2 BLK INP PHASE OV2 BLOCK
PH IOC3 LOW A /B / C BLK PH TOC3 LOW A /B /C BLK NEUTRAL DIR3 BLK INP PHASE OV3 BLOCK
NEUTRAL IOC1 BLOCK NEUTRAL TOC1 BLOCK GROUND DIR1 BLK INP NEUTRAL OV1 HIGH BLK
NEUTRAL IOC2 BLOCK NEUTRAL TOC2 BLOCK GROUND DIR2 BLK INP NEUTRAL OV2 HIGH BLK
NEUTRAL IOC3 BLOCK NEUTRAL TOC3 BLOCK GROUND DIR3 BLK INP NEUTRAL OV3 HIGH BLK
GROUND IOC1 BLOCK GROUND TOC1 BLOCK SENS GND DIR1 BLK IP NEUTRAL OV1 LOW BLK
GROUND IOC2 BLOCK GROUND TOC2 BLOCK SENS GND DIR2 BLK IP NEUTRAL OV2 LOW BLK
GROUND IOC3 BLOCK GROUND TOC3 BLOCK SENS GND DIR3 BLK IP NEUTRAL OV3 LOW BLK
SENS GND IOC1 BLK SENS GND TOC1 BLOCK
POWER BLOCKS AUXILIARY UV1 BLOCK
SENS GND IOC2 BLK SENS GND TOC2 BLOCK FWD PWR1 BLOCK AUXILIARY UV2 BLOCK
SENS GND IOC3 BLK SENS GND TOC3 BLOCK FWD PWR2 BLOCK AUXILIARY UV3 BLOCK
ISOLATED GROUND BLOCKS NEG SEQ TOC1 BLOCK FWD PWR3 BLOCK AUXILIARY OV1 BLOCK
ISOLATED GND1 BLK NEG SEQ TOC2 BLOCK DIR PWR1 BLOCK AUXILIARY OV2 BLOCK
ISOLATED GND2 BLK NEG SEQ TOC3 BLOCK DIR PWR2 BLOCK AUXILIARY OV3 BLOCK
ISOLATED GND3 BLK THERMAL MODEL BLOCKS DIR PWR3 BLOCK NEG SEQ OV1 BLOCK
SETTING GROUPS BLOCK IP THERMAL1 BLOCK 32N1 HIGH BLOCK NEG SEQ OV2 BLOCK
SETT GROUPS BLOCK THERMAL2 BLOCK 32N2 HIGH BLOCK NEG SEQ OV3 BLOCK
THERMAL3 BLOCK 32N3 HIGH BLOCK
LOCKED ROTOR BLK
BROKEN CONDUCTOR BLK 32N1 LOW BLOCK LOCKED ROTOR1 BLK
BROKEN CONDUCT1 BLK 32N2 LOW BLOCK LOCKED ROTOR2 BLK
BROKEN CONDUCT2 BLK 32N3 LOW BLOCK LOCKED ROTOR3 BLK
BROKEN CONDUCT3 BLK
FREQUENCY BLOCKS LOAD ENCROACHMENT BLKS
OVERFREQ1 BLOCK LOAD ENCR1 BLOCK
OVERFREQ2 BLOCK LOAD ENCR2 BLOCK
OVERFREQ3 BLOCK LOAD ENCR3 BLOCK
UNDERFREQ1 BLOCK
UNDERFREQ2 BLOCK
UNDERFREQ3 BLOCK
