GE F650 User Manual

11-8 F650 Digital Bay Controller GEK-106310AB
11.3 EXAMPLE 3: PROCEDURE TO SET AN OPERATION 11 APPLICATION EXAMPLES
11
11.3EXAMPLE 3: PROCEDURE TO SET AN OPERATION 11.3.1 DESCRIPTION OF THE EXERCISE
This simple operation describes how to program and set an operation command on the F650 relay. In the present case the
operation is:
To configure some F650 output contact to be operated since the front of the relay.
To set some LED to show the operation of the output contact (while being closed).
To close a F650 output contact using a front key pushbutton.
To reset the output contact and LED using another front key pushbutton.
11.3.2 PROCEDURE
Set the following values:
Under
SETPOINT  CONTROL ELEMENTS  INPUTS/OUTPUTS  BOARD F
* This setting is non-relevant since it applies only when “pulse” type is chosen
Under
SETPOINT  RELAY CONFIGURATION  OUTPUTS
Under
SETPOINT  RELAY CONFIGURATION  LEDS
NAME VALUE
Output Logic_00_00 Positive
Output Type_00_00 Latch
Pulse Output Time 10000ms *
SELECT NAME SOURCE
Contact Output Operate 00 (Board F)
C_Output Oper_00_00 Operation_bit000
Contact Output Reset 00 (Board F)
C_Output Reset_00_00 Operation_bit001
SELECT NAME SOURCE
Led 14
Close Contact_00_00 C_Output_00_00
