4–374 869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
TESTING CHAPTER 4: SETPOINTS
Test LEDs
The Test LEDs section is used to program the state and color of each LED when in test
mode and Force LEDs is “Enabled”.
NOTE:
Test LEDs setpoints here (in test mode) will revert to default values at power-up.
Path:
Setpoints > Testing > Test LEDs
LED 1 (17)
Range: Off, Red, Green, Orange
Default: Off
Description of Test Leds
Contact Inputs
The Contact Inputs section is used to program the state of each contact input when in test
mode. The number of Contact Inputs available is dependent on the installed Order Code
options.
NOTE:
Contact Inputs setpoints here (in test) will revert to default values at power-up.
Path:
Setpoints > Testing > Contact Inputs
CI 1(X):
Range: Off, On
Default: Off
The item name displays the user configurable name for the contact input.
Output Relays
The Output Relays section is used to program the state of each output relay when the
device is in test mode and Force Relays is “Enabled”.
Select “Off” to force the output relay to the de-energized state, or select “On” to force the
output r
elay to the energized state.
The number of Output Relays available is dependent on the installed Order Code options.
NOTE:
Output Relays setpoints here (in test mode) will revert to default values at power-up.
Path:
Setpoints > Testing > Output Relays
OUTPUT RELAY 1(X):
Range: Off, On
Default: Off
To Next Page
