CHAPTER 6: METERING ENERGY
869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL 6–15
Apparent Total (Apparent)
Range: 0 kVA to 214748364.7 kVA
Phase A Real (Ph A Real)
Range: - 214748364.8 kW to 214748364.7 kW
Phase B Real (Ph B Real)
Range: - 214748364.8 kW to 214748364.7 kW
Phase C Real (Ph C Real)
Range: - 214748364.8 kW to 214748364.7 kW
Phase A Reactive (Ph A Reactive)
Range: - 214748364.8 kvar to 214748364.7 kvar
Phase B Reactive (Ph B Reactive)
Range: - 214748364.8 kvar to 214748364.7 kvar
Phase C Reactive (Ph C Reactive)
Range: - 214748364.8 kvar to 214748364.7 kvar
Phase A Apparent (Ph A Apparent)
Range: 0 kVA to 214748364.7 kVA
Phase B Apparent (Ph B Apparent)
Range: 0 kVA to 214748364.7 kVA
Phase C Apparent (Ph C Apparent)
Range: 0 kVA to 214748364.7 kVA
Power Factor Total (PF)
Range: 0.01 Lag to 1.00 to 0.01 Lead
Phase A Power Factor (Ph A PF)
Range: 0.01 Lag to 1.00 to 0.01 Lead
Phase B Power Factor (Ph B PF)
Range: 0.01 Lag to 1.00 to 0.01 Lead
Phase C Power Factor (Ph C PF)
Range: 0.01 Lag to 1.00 to 0.01 Lead
Energy
Path: Metering > Energy 1
Reset (Reset Energy Date/Time) MM/DD/YY 00:00:00
Positive Watt Hours (Pos WattHours)
Ran
ge: 0.0 MWh to 214748364.7 MWh
Negative Watt Hours (Neg WattHours)
Range: 0.0 MWh to 214748364.7 MWh
Positive Var Hours (Pos VarHours)
Range: 0.0 Mvarh to 214748364.7 Mvarh
Negative Var Hours (Neg VarHours)
Range: 0.0 Mvarh to 214748364.7 Mvarh
